In this video, Grammy Award Winner Cory Henry visits the Moog Factory to put the new Subsequent 37 through its paces, and Moog Music's Chief Engineer compares the audio output from the Sub 37 Tribute Edition and the new Subsequent 37 using an audio precision analyzer and oscilloscope.

• SOUND ENGINE

  Analog

• POLYPHONY

  Selectable Monophonic or Paraphonic (can be poly-chained)

• KEYBED

  37 Note Semi-weighted with After Pressure

• LCD

  128 X 64 pixel LCD with white backlight

• CONTROLLERS

  Pitch Bend, Mod Wheel, After Pressure, Velocity

• SOUND SOURCES

  2 Variable Waveshape Oscillators, 1 Square Wave Sub Oscillator, 1 Analog Noise Generator, 1 External Input/Filter Feedback

• OSCILLATOR CALIBRATION RANGE

  22Hz-6.8KHz. Note range at 8’ = 18 - 116

• GLIDE MODULE

  Assign to Osc1/Osc2/Both. Type - LCR, LCT, EXP, Gated, Legato

• FILTER

  20Hz-20KHz Moog Ladder Filter w/ 6/12/18/24 dB/Oct Filter Slopes and MultiDrive

• TRANSPOSE

  +/- 2 Octaves

• ARPEGGIATOR/SEQUENCER

  Up, Down, Order, Random, Latching, Back/Forth, Invert, +/-2 Range, Tie, Rest, MIDI Sync, 64-note sequencer

• MODULATION SOURCES

  LFO (Triange, Square, Saw, Ramp, Sample & Hold), Filter

• EG/PM

  Amp Env, Constant ON, Sine LFO, Noise LFO, Osc 1 Pitch, Osc 2 Pitch, Seq Note, Seq Vel, and Seq Mod.

• MODULATION DESTINATIONS

  Osc 1 Pitch, Osc 2, Osc 1 & 2 Pitch, Filter, LFO Rate, VCA Level, Osc 1 Wave, Osc 2 Wave, Osc 1 & 2 Wave, Noise Level, EG Time/PGM - Filter Resonance, Filter Drive, Filter Slope, Filter Env Amount, Filter Keyboard Amount, Osc 1 Level, Sub Osc Level, Osc 2 Level, External In/Feedback Level, Osc 1 On, Sub Osc On, Osc 2 On, Noise On, External In/Feedback On, Arp Rate, Arp Clock Division, Arp Range, Arp Back/Forth, Arp Ends, Arp Invert, Arp Gate Length, Arp Run, Glide Time, Glide OSC Choice, Glide Type, Glide Gate, Glide Legato, Glide On, LFO 1 Clock Division, LFO 1 Range, LFO 1 Sync, LFO 1 Keyboard Reset, LFO 1 Keyboard Track, Mod 1 Pitch Amount, Mod 1 Filter Amount, Mod 1 Programmable Amount, Mod 1 Programmable Destination, LFO 2 Clock Division, LFO 2 Range, LFO 2 Sync, LFO 2 Keyboard Reset, LFO 2 Keyboard Track, Mod 2 Pitch Amount, Mod 2 Filter Amount, Mod 2 Programmable Amount, Mod 2 Programmable Destination, Osc 1 Oct, Osc 2 Sync, Osc 2 Keyboard Reset, Osc 2 Oct, Osc 2 Keyboard Control, Osc 2 DUO Mode, Osc 2 Freq, Osc 2 Beat Freq, Filter Env Attack, Filter Env Decay, Filter Env Sus, Filter Env Release, Filter Env Delay, Filter Env Hold, Filter Env Vel Amount, Filter Keyboard Track, Filter Env Multitriggering, Filter Env Reset, Filter Env Sync, Filter Env Loop, Filter Env Latch, Amp Env Attack, Amp Env Decay, Amp Env Sus, Amp Env Release, Amp Env Delay, Amp Env Hold, Amp Env Vel Amount, Amp Keyboard Track, Amp Env Multitriggering, Amp Env Reset, Amp Env Sync, Amp Env Loop, Amp Env Latch, Output Volume, Bend Up, and Bend Down.

•





• LFO PANEL FEATURES

  Hi/Low Range from .01Hz–1kHz, MIDI Sync, KB Reset

• ENVELOPES

  DAHDSR Envelopes with Multi-Trigger, Reset, Looping, MIDI Sync, Latch, and Variable control of EG Delay, Hold, Velocity Amount, KB Tracking.

• EXTERNAL AUDIO INPUT

  ¼” TS

• AUDIO OUTPUT

  ¼” TS, ¼” TRS Headphones

• PRESETS

  256 Presets - 16 Banks x 16 presets

• MIDI I/O

  DIN In/Out, and MIDI over USB

• CV/GATE INPUTS

  Filter CV, Pitch CV, Volume CV, KB Gate

• POWER

  110VAC-240VAC Universal Power Supply with IEC connector

• WEIGHT

  22lbs

• DIMENSIONS

  6.75H x 26.75”W x 14.75”D

•


  Specifications subject to change without notice.
