• Classic SPD-20 Sounds—and More

  The SPD-20 has been embraced by thousands of players as a primary instrument, and they rely on its versatile sound set for performing every day. The OCTAPAD SPD-20 PRO retains every sound from the original percussion pad while also providing an impressive selection of new ones to choose from. In addition, EQ, compression, and three onboard effects engines—each with 38 multi-effects types—can be applied to a single instrument, further broadening the sonic possibilities.

• Authentic Sounds from Around the World

  The OCTAPAD SPD-20 PRO’s new sounds give players what they need to meet today’s diverse live performance and studio production demands. Sampled in the highest quality, these premium sounds allow percussionists to authentically cover Asian, African, Latin, and many other world music styles. Traditional drum kit sounds are also on tap, including high-end acoustic drums and cymbals originally developed for the TD-27 V-Drums sound module. In total, more than 900 instruments are available for musical exploration.

• Real-Time Sound Editing for Expressive Performances

  The OCTAPAD SPD-20 PRO comes with 100 great-sounding preset kits that are ready to play. But you also have the ability to customize them to perfectly fit your personal style and the music you’re playing. The backlit LCD and direct-access buttons support real-time editing of instrument sounds as you perform, and up to four sounds can be layered on any one pad using the pad link function to create exciting new tones and textures. Additionally, the kit chain function lets you line up kits to match your set list, making it easy to call up the exact one you need during a performance.

• Expand Beyond the Built-In Pads

  To complement its eight sensitive rubber pads, the OCTAPAD SPD-20 PRO features four dual-trigger inputs and a dedicated hi-hat control input. This allows you to build an expanded percussion setup with a variety of optional Roland trigger pads, including mesh-head V-Pads, V-Cymbals, and the BT-1 Bar Trigger Pad. And by connecting a Roland kick pad and hi-hat control pedal, you can transform the OCTAPAD SPD-20 PRO into a powerhouse mini drum kit with rock-solid feel and continuous open/closed hi-hat sounds.

• Legendary Roland Quality

  Roland instruments are renowned for their durability and longevity, and this percussion pad is no exception. Designed in Japan, the briefcase-size OCTAPAD SPD-20 PRO gives you all the sounds you need in one dependable, road-ready instrument.

SPECIFICATIONS

Pads

Built-in Pads: 8
* Four external trigger inputs are provided, allowing you to connect Pads.

Instruments

Instruments: 900 instruments or greater

Kits

200 (Preset: 100)

Kit Chain

16 chains (16 steps per chain)

Layer

2 layers per pad
2 layers x 2(Head/Rim) per external Trigger

Instrument /Pad Parameters

Volume
Curve
Coarse Tune
Fine Tune
Pedal Bend
Decay
Output
Layer EQ
Pad comp
Pad Mute Group
Pad Link

Kit Effects

Ambience (5 Types)
Kit EQ
Kit Comp
MFX : 3 systems, 38 types

Display

16 characters 2 line (backlit LCD)
7 segments, 3 characters (LED)

Connectors

PHONES Jack: Stereo 1/4-inch phone type
OUTPUT(L/MONO, R) Jacks: 1/4-inch phone type
MIX IN Jack: Stereo 1/4-inch phone type
EXTERNAL TRIGGER INPUT Jack : 1/4-inch TRS phone type x 4
HH CTRL Jack: 1/4-inch phone type
FOOT SW Jack: 1/4-inch TRS phone type
MIDI (IN, OUT) Connectors
USB MEMORY port: USB A type

Power Supply

AC adaptor (DC 12 V)

Current Draw

500 mA

SIZE AND WEIGHT

Dimensions

450(W) x 350 (D) x 72 (H) mm
17-3/4 (W) x 13-13/16 (D) x 2-7/8 (H) inches

Weight

3.7 kg / 8 lbs 3 oz (excluding AC Adaptor)

OTHER

Accessories

Owner's Manual
AC Adaptor

Options (sold separately)

Pads (PD series, PDX series, BT series)
Cymbals (CY series)
Kick Triggers (KD series, KT Series)
Hi-Hats (VH-11/10)
Hi-Hat Control Pedal (FD series)
Pad Stand (PDS series)
All-Purpose Clamp (APC series)
Acoustic Drum Trigger (RT series)
Footswitch (FS series, excluding Latch-type)
Personal Drum Monitor (PM series)
