K Gear

K Gear GPX Passive System 2x18" Subwoofer + GH412 Co-Axial Stainless Steel Slim Array Black

K Gear GPX Passive System 2x18" Subwoofer + GH412 Co-Axial Stainless Steel Slim Array Black

Regular price Rs. 993,550.00
Regular price Sale price Rs. 993,550.00
Sale Sold out
Tax included.

K Gear LogoPassive System 2x18" Subwoofer + GH412 Co-Axial Stainless Steel Slim Array Black Color

GPX

2x18" Subwoofer + 4x12" Slim Array System (Passive)

GPX is our top of the line high performance¬†passive system and comprises of a¬†2x18‚ÄĚ subwoofer combined with GH412, our 4x12‚ÄĚ coaxial¬†slim array with¬†K-array‚ĄĘ SAT¬ģ (Slim Array Technology), PAT¬ģ (Pure Array Technology) and a stainless steel cabinet.¬†

This system can be driven by GPXA active system in a stereo configuration or by GA46 power amplifiers.

Thanks to its extreme performance and the compact format of the array, this system works in a stack configuration, with the array on top of the subwoofer. It is also possible to fly GH412 with our GH-FLY flybar accessory, or place it on the ground with our GH-BASE accessory.

Perfect for high SPL outdoor/indoor applications in large venues both for rental and permanent installations for touring, auditoriums, stadia, clubs, theme parks.

User Tip: optimize the cost and combine the system with the active model whether it is for stereo configurations or if need to extend the satellite cluster to form an array.

Tech specs

GENERAL

Power Handling: 1500W subwoofer + 750W satellite
Peak Power: 3000W subwoofer + 1500W satellite
Impedance: 4ő© subwoofer + 8ő© satellite¬†
Frequency Range: 30 Hz - 20 KHz (-6 dB average)
Maximum SPL(1): 140dB (peak)
Continuos SPL: 128dB
Coverage: V.30¬į - H.90¬į¬†

TRANSDUCERS

Subwoofer: 2x18‚ÄĚ ferrite magnet¬†

Mid High Frequency: 4x12‚ÄĚ coaxial with 1‚ÄĚ compression driver ferrite magnet

AUDIO I/O

Speakon



PHYSICAL OVERVIEW

SUBWOOFER

Width: 1035mm (40,75in)
Height: 614mm (24,17in)
Depth: 600mm (23,6in)
Weight: 58kg (127,88lbs)
Material: birch plywood
Rating: IP43

SATELLITE

Width: 327mm (12,87in)
Height: 1290mm (50,79in)
Depth: 198mm (7,79in)
Weight: 55,2kg (121,69lbs)
Material: stainless steel
Rating: IP54

ACCESSORIES
GPINM20: M20 pin (included)
K-SPKCABLE15: 15m/49ft Speakon cable (included)
K-SPKCABLE2: 2m/6,6ft Speakon sub to satellite cable (included)
GH-BASE: Floor stacking hardware for GH12/GH412 (optional)
GH-JOINT: Adjustable stacking hardware for GH12/GH412 (optional)

Accessories

GH-FLY

Fly bar for GH412 / GH12

GH-BASE

Stacking hardware for GH412 / GH12

GH-JOINT

2 lugs 8 pins rigging set for GH412 /GH12

GS218-COVER

Cover for KGEAR 2x18" subwoofers w/ logo
