iD14
Your recordings made better

Designed to take your recordings to the next level in every way, the iD14 (MKII) delivers professional audio performance in a compact and modern desktop package, giving you everything you need to make studio quality recordings at home.

10-in/6-out high performance USB C Audio Interface with 2 Class-A Audient Console Mic Preamps, 8-channel ADAT Input, JFET DI, Burr-Brown AD/DA Converters, Monitor Control Functionality and iD Scroll Control Mode

Features:
● 2 x Audient Console Mic Pre
● Class Leading Converters
● 1 x JFET Instrument Input
● 4 x Line Outputs
● Dual Headphone Outputs
● ADAT Input for Expandability
● Ultra Low Latency Software Mixer
● Advanced Monitor Control
● Scrollcontrol
● True Phantom Power over USB
● USB3.0 Bus Powered
● All Metal Design
● Free Software + Plugin

iD14

10in/6out Audio Interface

Designed to take your recordings to the next level in every way, the iD14MKII delivers professional audio performance in a compact and modern desktop package. Featuring two Audient Console mic pre’s, class leading converters, dual headphone outputs, ADAT expandability and a JFET Instrument Input, the next generation MKII gives you everything you need to create studio quality recordings at home.

The professional sound you deserve
Audient Console Mic Pres

Every iD interface features the Audient Console Mic Preamp, the same discrete circuit design found in our renowned recording console the ASP8024-HE. Designed to deliver ultra- low noise and low distortion with a touch of classic analogue warmth, iD14’s two Audient mic pre’s will give you the professional sound you deserve.

It’s all in the detail
Class Leading Converters

iD14’s converters make sure you hear every nuance, every detail of your audio, enabling you to take your recordings to the next level. Offering an incredible 121dB of dynamic range you will hear your audio more accurately, make better creative decisions and experience stunning clarity directly from your desktop.

Be immersed
Speaker outputs

Connect and listen to your mixes through two sets of speakers with iD14’s four line outputs. Alternatively use the extra line outputs to send audio to an external headphone amp for distribution to your artists.

Powerful Performance
Dual Headphone Outputs

Equipped with both a jack and mini jack connection and a powerful headphone amp capable of driving headphones up to 600Ohms, iD14 is ready to take on the most demanding recording sessions.

More channels, more possibilities
Expand via ADAT

Plan for the future with iD14’s digital input. Supporting both ADAT and SPDIF, iD14 gives you the option to add up to eight extra mic pre inputs letting you expand your rig and take on larger sessions.

Plug and Play
JFET Instrument Input

Designed to replicate the input stage of a classic valve amplifier, iD14’s harmonically rich JFET Instrument Input is the perfect sonic foundation for your guitar or bass as well as your amp sims.

Experience ultra low latency
Software Mixer

Keep it simple with the powerful but intuitive iD Mixer. Create and customise low latency headphone mixes, utilise the flexible monitor control or simply keep an eye on your levels – all from one easy to use app.

Innovation meets communication
Talkback

iD14’s dedicated talkback technology enables you to use any audio source connected to your computer such as a built in or USB microphone as your talkback mic, freeing up valuable mic pres for recording.

Work faster
Advanced Monitor Control

Speed up your workflow with the iD button. Assign any of iD14’s advanced monitoring features to the iD button, including DIM, CUT, Polarity Reverse, Mono Sum, Talkback or Cue Mix monitoring, and experience complete control at your fingertips.

The virtual scroll wheel
ScrollControl

Turn iD14’s volume knob into a virtual scroll wheel and take control of a variety of compatible onscreen parameters. Quickly dial in settings, adjust faders or even write in automation without spending hours staring at the screen.

Set up in seconds
USB Bus Powered

No need to find a power outlet as iD14 is powered directly from your computer via USB, without compromising on sound quality or performance.

Get the most from your mics
True Phantom Power

Designed to deliver true phantom power over USB, iD14 will make sure your mics get the power they need to ensure optimal sonic performance.

Built to Last
All metal construction

Engineered to survive everyday use, iD14 delivers professional quality audio in a small, beautifully engineered and all-metal package.

Create instantly
Free Software with ARC

Bundled with a free suite of creative software including Cubase LE, alongside industry leading plugins and virtual instruments, you can start recording as soon as you open the box.

iD14 Specifications:

Key tech specs Mic gain: 58dB
Mic pre EIN: 128dB A-Weighted
Mic pre SNR: 100dB A-Weighted Mic pre THD+N: <0.002%
Frequency response (at unity gain): ±0.5dB 10Hz to 40kHz

ADC Dynamic range: 121dB ADC THD+N: <0.001%

Line output dynamic range: 126dB A-Weighted Line output THD+N: 0.0005%
Frequency Response: ±0.1dB 10Hz to 40kHz

Headphone amp (with USB-C host):
Max Power with 30Ohm load: 220mW Max Power with 62Ohm load: 280mW Max Power with 600Ohm load: 100mW

Power requirements:
USB 3.0 – 900mA at 5V or USB-C – 1.5A at 5V

iD4 iPad Support Note: Older/low end iPads might not be supported – recommend use with USB-C enabled iPads. Need to verify older iPads.

Included Cable:
USC Type C- Type C 1m
